PJ橡胶多楔带设计参数：楔距：2.34mm；带厚：3.6±0.2mm；楔角：40度；楔根圆角半径：0.2mm；楔顶圆角半径：0.4mm；楔高：1.6mm
PJ橡胶多楔带具有一定的耐寒与耐热性能、耐老化、抗臭氧老化性、耐气候性，不但耐屈挠性能良好，而且其电绝缘性能、耐化学腐蚀、冲击弹性较好（在低温下弹性保持性能较好），有良好的耐油、耐溶剂及化学稳定性，加入短纤维补强可承受较高的横向压力，增加带楔耐压性能，减少受力后变形。
PJ橡胶多楔带兼有v带和平带二者的优点，既有平带的柔软、强韧的特点，又有v带紧凑、高效等优点。
PJ橡胶多楔带主要特点如下：
1.传动功率大，空间相同时比普通V带的传动功卒的高30％。
2.传动系统结构紧凑，在相同的传动功率情况下，传递装置所占空间比普通V带小25％。
3.带体薄，富有柔软性，适应带轮直径小的传动，也适应高速传动，带速可达40m／s；振动小，发热少，运转平稳。
4.耐热、耐油、耐磨，使用伸长小，寿命长。
龙韵公司生产销售的PJ橡胶多楔带系列产品，引进国外先进技术和生产设备，产品的主要原材料（如骨架材料、橡胶等）均从国外领先的专业生产公司采购进口。产品已通过国家级技术鉴定，可替换同种型号进口PJ橡胶多楔带。
型 号 | 有效长度(mm) | 型 号 | 有效长度(mm) | 型 号 | 有效长度(mm) |
PJ356 | 356.00 | PJ955 | 955.00 | PJ1730 | 1730.00 |
PJ360 | 360.00 | PJ958 | 958.00 | PJ1735 | 1735.00 |
PJ366 | 366.00 | PJ965 | 965.00 | PJ1740 | 1740.00 |
PJ370 | 370.00 | PJ966 | 966.00 | PJ1751 | 1751.00 |
PJ376 | 376.00 | PJ970 | 970.00 | PJ1766 | 1766.00 |
PJ381 | 381.00 | PJ978 | 978.00 | PJ1783 | 1783.00 |
PJ390 | 390.00 | PJ981 | 981.00 | PJ1790 | 1790.00 |
PJ392 | 392.00 | PJ986 | 986.00 | PJ1812 | 1812.00 |
PJ401 | 401.00 | PJ991 | 991.00 | PJ1855 | 1855.00 |
PJ406 | 406.00 | PJ996 | 996.00 | PJ1861 | 1861.00 |
PJ411 | 411.00 | PJ1003 | 1003.00 | PJ1876 | 1876.00 |
PJ416 | 416.00 | PJ1008 | 1008.00 | PJ1880 | 1880.00 |
PJ431 | 431.00 | PJ1014 | 1014.00 | PJ1892 | 1892.00 |
PJ442 | 442.00 | PJ1016 | 1016.00 | PJ1900 | 1900.00 |
PJ446 | 446.00 | PJ1020 | 1020.00 | PJ1920 | 1920.00 |
PJ457 | 457.00 | PJ1022 | 1022.00 | PJ1941 | 1941.00 |
PJ477 | 477.00 | PJ1028 | 1028.00 | PJ1950 | 1950.00 |
PJ482 | 482.00 | PJ1032 | 1032.00 | PJ1960 | 1960.00 |
PJ498 | 498.00 | PJ1036 | 1036.00 | PJ1997 | 1997.00 |
PJ505 | 505.00 | PJ1041 | 1041.00 | PJ2000 | 2000.00 |
PJ508 | 508.00 | PJ1046 | 1046.00 | PJ2004 | 2004.00 |
PJ521 | 521.00 | PJ1054 | 1054.00 | PJ2016 | 2016.00 |
PJ528 | 528.00 | PJ1060 | 1060.00 | PJ2035 | 2035.00 |
PJ533 | 533.00 | PJ1067 | 1067.00 | PJ2040 | 2040.00 |
PJ541 | 541.00 | PJ1072 | 1072.00 | PJ2050 | 2050.00 |
PJ552 | 552.00 | PJ1078 | 1078.00 | PJ2060 | 2060.00 |
PJ559 | 559.00 | PJ1080 | 1080.00 | PJ2075 | 2075.00 |
PJ571 | 571.00 | PJ1087 | 1087.00 | PJ2096 | 2096.00 |
PJ586 | 586.00 | PJ1089 | 1089.00 | PJ2100 | 2100.00 |
PJ594 | 594.00 | PJ1092 | 1092.00 | PJ2110 | 2110.00 |
PJ600 | 600.00 | PJ1098 | 1098.00 | PJ2124 | 2124.00 |
PJ605 | 605.00 | PJ1102 | 1102.00 | PJ2140 | 2140.00 |
PJ606 | 606.00 | PJ1106 | 1106.00 | PJ2145 | 2145.00 |
PJ610 | 610.00 | PJ1112 | 1112.00 | PJ2210 | 2210.00 |
PJ614 | 614.00 | PJ1117 | 1117.00 | PJ2225 | 2225.00 |
PJ620 | 620.00 | PJ1124 | 1124.00 | PJ2256 | 2256.00 |
PJ626 | 626.00 | PJ1130 | 1130.00 | PJ2267 | 2267.00 |
PJ635 | 635.00 | PJ1137 | 1137.00 | PJ2337 | 2337.00 |
PJ638 | 638.00 | PJ1144 | 1144.00 | PJ2340 | 2340.00 |
PJ640 | 640.00 | PJ1152 | 1152.00 | PJ2376 | 2367.00 |
PJ646 | 646.00 | PJ1156 | 1156.00 | PJ2405 | 2405.00 |
PJ651 | 651.00 | PJ1166 | 1166.00 | PJ2465 | 2465.00 |
PJ656 | 656.00 | PJ1168 | 1168.00 | PJ2575 | 2575.00 |
PJ660 | 660.00 | PJ1180 | 1180.00 | PJ2605 | 2605.00 |
PJ666 | 666.00 | PJ1185 | 1185.00 | PJ2665 | 2665.00 |
PJ670 | 670.00 | PJ1194 | 1194.00 | PJ2755 | 2755.00 |
PJ674 | 674.00 | PJ1216 | 1216.00 | PJ2834 | 2834.00 |
PJ685 | 685.00 | PJ1220 | 1220.00 | PJ2836 | 2836.00 |
PJ690 | 690.00 | PJ1225 | 1225.00 | PJ2845 | 2845.00 |
PJ700 | 700.00 | PJ1230 | 1230.00 | PJ2879 | 2879.00 |
PJ711 | 711.00 | PJ1235 | 1235.00 | PJ2926 | 2926.00 |
PJ720 | 720.00 | PJ1242 | 1242.00 | PJ2940 | 2940.00 |
PJ736 | 736.00 | PJ1256 | 1256.00 | PJ2960 | 2960.00 |
PJ740 | 740.00 | PJ1270 | 1270.00 | PJ3030 | 3030.00 |
PJ752 | 752.00 | PJ1290 | 1290.00 | PJ3086 | 3086.00 |
PJ761 | 761.00 | PJ1300 | 1300.00 | PJ3150 | 3150.00 |
PJ766 | 766.00 | PJ1315 | 1315.00 | PJ3200 | 3200.00 |
PJ772 | 772.00 | PJ1321 | 1321.00 | PJ3416 | 3416.00 |
PJ776 | 776.00 | PJ1330 | 1330.00 | PJ3476 | 3476.00 |
PJ787 | 787.00 | PJ1337 | 1337.00 | PJ3572 | 3572.00 |
PJ796 | 796.00 | PJ1341 | 1341.00 | PJ3598 | 3598.00 |
PJ801 | 801.00 | PJ1355 | 1355.00 | PJ3686 | 3686.00 |
PJ806 | 806.00 | PJ1394 | 1394.00 | PJ4361 | 4361.00 |
PJ810 | 810.00 | PJ1396 | 1396.00 | PJ4456 | 4456.00 |
PJ813 | 813.00 | PJ1420 | 1420.00 | PJ4503 | 4503.00 |
PJ816 | 816.00 | PJ1435 | 1435.00 | PJ4646 | 4646.00 |
PJ822 | 822.00 | PJ1444 | 1444.00 | PJ4807 | 4807.00 |
PJ827 | 827.00 | PJ1456 | 1456.00 | PJ5377 | 5377.00 |
PJ830 | 830.00 | PJ1460 | 1460.00 | PJ5511 | 5511.00 |
PJ838 | 838.00 | PJ1480 | 1480.00 | PJ5926 | 5926.00 |
PJ841 | 841.00 | PJ1488 | 1488.00 | PJ6027 | 6027.00 |
PJ846 | 846.00 | PJ1510 | 1510.00 | PJ6196 | 6196.00 |
PJ851 | 851.00 | PJ1511 | 1511.00 | PJ6276 | 6276.00 |
PJ856 | 856.00 | PJ1516 | 1516.00 | PJ7056 | 7056.00 |
PJ864 | 864.00 | PJ1523 | 1523.00 | PJ7141 | 7141.00 |
PJ870 | 870.00 | PJ1551 | 1551.00 | ||
PJ876 | 876.00 | PJ1570 | 1570.00 | ||
PJ880 | 880.00 | PJ1581 | 1581.00 | ||
PJ886 | 886.00 | PJ1593 | 1593.00 | ||
PJ900 | 900.00 | PJ1600 | 1600.00 | ||
PJ906 | 906.00 | PJ1635 | 1635.00 | ||
PJ914 | 914.00 | PJ1641 | 1641.00 | ||
PJ917 | 917.00 | PJ1636 | 1636.00 | ||
PJ927 | 927.00 | PJ1650 | 1650.00 | ||
PJ931 | 931.00 | PJ1655 | 1655.00 | ||
PJ940 | 940.00 | PJ1660 | 1660.00 | ||
PJ942 | 942.00 | PJ1696 | 1696.00 | ||
PJ944 | 944.00 | PJ1712 | 1712.00 | ||
PJ952 | 952.00 | PJ1725 | 1725.00 |
