PL rubber multi-wedge belt design parameters: wedge distance: 4.7mm; Band thickness: 7±0.3mm; Wedge Angle: 40 degrees; Wedge root radius: 0.3mm; Wedge top corner radius: 0.8mm; Wedge height: 4.3mm
PL rubber multi-wedge belt has certain cold and heat resistance, aging resistance, ozone aging resistance, weather resistance, not only good flexural performance, but also its electrical insulation performance, chemical corrosion resistance, impact elasticity is good (elastic retention performance is good at low temperature), has good oil resistance, solvent resistance and chemical stability, adding short fiber reinforcement can withstand high transverse pressure. Increase the compression resistance of the band wedge and reduce the deformation after stress.
PL rubber multi-wedge belt has the advantages of both V-belt and flat belt, both soft and strong characteristics of flat belt, but also has the advantages of V-belt compact and efficient.
PL rubber multi-wedge tape main features are as follows:
1. The transmission power is large, and the transmission power of the ordinary V-belt is 30% higher than that of the same space.
2. The transmission system has a compact structure, and the space occupied by the transmission device is 25% smaller than that of the ordinary V-belt under the same transmission power.
3. The belt body is thin, full of softness, suitable for the transmission with small diameter of the belt wheel, and also suitable for high-speed transmission, with a speed of 40m/s; Small vibration, less heat, smooth operation.
4. Heat resistance, oil resistance, wear resistance, small elongation, long life.
Longyun company production and sales of PL rubber multi-wedge belt series products, the introduction of foreign advanced technology and production equipment, the main raw materials (such as skeleton materials, rubber, etc.) are purchased from foreign leading professional production companies. The product has passed the national technical appraisal, can replace the same type of imported PL rubber multi-wedge belt.
Model number | Effective length (mm) | Model number | Effective length (mm) | Model number | Effective length (mm) |
PL600 | 600.00 | PL1055 | 1055.00 | PL1945 | 1945.00 |
PL605 | 605.00 | PL1060 | 1060.00 | PL1934 | 1934.00 |
PL610 | 610.00 | PL1064 | 1064.00 | PL1944 | 1944.00 |
PL618 | 618.00 | PL1071 | 1071.00 | PL1980 | 1980.00 |
PL622 | 622.00 | PL1075 | 1075.00 | PL1985 | 1985.00 |
PL624 | 624.00 | PL1080 | 1080.00 | PL1988 | 1988.00 |
PL630 | 630.00 | PL1085 | 1085.00 | PL2000 | 2000.00 |
PL635 | 635.00 | PL1090 | 1090.00 | PL2018 | 2018.00 |
PL640 | 640.00 | PL1096 | 1096.00 | PL2024 | 2024.00 |
PL644 | 644.00 | PL1100 | 1100.00 | PL2034 | 2034.00 |
PL650 | 650.00 | PL1107 | 1107.00 | PL2044 | 2044.00 |
PL653 | 653.00 | PL1115 | 1115.00 | PL2058 | 2058.00 |
PL658 | 658.00 | PL1121 | 1121.00 | PL2080 | 2080.00 |
PL667 | 667.00 | PL1128 | 1128.00 | PL2085 | 2085.00 |
PL674 | 674.00 | PL1135 | 1135.00 | PL2095 | 2095.00 |
PL685 | 685.00 | PL1139 | 1139.00 | PL2105 | 2105.00 |
PL695 | 695.00 | PL1150 | 1150.00 | PL2125 | 2125.00 |
PL703 | 703.00 | PL1152 | 1152.00 | PL2129 | 2129.00 |
PL720 | 720.00 | PL1164 | 1164.00 | PL2193 | 2193.00 |
PL723 | 723.00 | PL1169 | 1169.00 | PL2209 | 2209.00 |
PL735 | 735.00 | PL1180 | 1180.00 | PL2240 | 2240.00 |
PL745 | 745.00 | PL1200 | 1200.00 | PL2251 | 2251.00 |
PL750 | 750.00 | PL1204 | 1204.00 | PL2269 | 2269.00 |
PL756 | 756.00 | PL1210 | 1210.00 | PL2323 | 2323.00 |
PL760 | 760.00 | PL1214 | 1214.00 | PL2344 | 2344.00 |
PL769 | 769.00 | PL1220 | 1220.00 | PL2360 | 2360.00 |
PL780 | 780.00 | PL1225 | 1225.00 | PL2385 | 2385.00 |
PL785 | 785.00 | PL1240 | 1240.00 | PL2445 | 2445.00 |
PL790 | 790.00 | PL1254 | 1254.00 | PL2460 | 2460.00 |
PL793 | 793.00 | PL1274 | 1274.00 | PL2480 | 2480.00 |
PL795 | 795.00 | PL1285 | 1285.00 | PL2570 | 2570.00 |
PL800 | 800.00 | PL1300 | 1300.00 | PL2650 | 2650.00 |
PL805 | 805.00 | PL1305 | 1305.00 | PL2820 | 2820.00 |
PL810 | 810.00 | PL1314 | 1314.00 | PL2830 | 2830.00 |
PL815 | 815.00 | PL1321 | 1321.00 | PL2860 | 2860.00 |
PL820 | 820.00 | PL1325 | 1325.00 | PL2910 | 2910.00 |
PL825 | 825.00 | PL1339 | 1339.00 | PL2939 | 2939.00 |
PL830 | 830.00 | PL1378 | 1378.00 | PL3070 | 3070.00 |
PL835 | 835.00 | PL1380 | 1380.00 | PL3165 | 3165.00 |
PL840 | 840.00 | PL1404 | 1404.00 | PL3178 | 3178.00 |
PL848 | 848.00 | PL1419 | 1419.00 | PL3183 | 3183.00 |
PL854 | 854.00 | PL1428 | 1428.00 | PL3399 | 3399.00 |
PL860 | 860.00 | PL1440 | 1440.00 | PL3459 | 3459.00 |
PL863 | 863.00 | PL1444 | 1444.00 | PL3555 | 3555.00 |
PL870 | 870.00 | PL1459 | 1459.00 | PL3581 | 3581.00 |
PL877 | 877.00 | PL1463 | 1463.00 | PL3669 | 3669.00 |
PL882 | 882.00 | PL1472 | 1472.00 | PL4344 | 4344.00 |
PL890 | 890.00 | PL1494 | 1494.00 | PL4439 | 4439.00 |
PL895 | 895.00 | PL1495 | 1495.00 | PL4486 | 4486.00 |
PL901 | 901.00 | PL1500 | 1500.00 | PL4629 | 4629.00 |
PL910 | 910.00 | PL1507 | 1507.00 | PL4790 | 4790.00 |
PL915 | 915.00 | PL1535 | 1535.00 | PL5360 | 5360.00 |
PL920 | 920.00 | PL1552 | 1552.00 | PL5494 | 5494.00 |
PL925 | 925.00 | PL1565 | 1565.00 | PL5909 | 5909.00 |
PL928 | 928.00 | PL1577 | 1577.00 | PL6010 | 6010.00 |
PL935 | 935.00 | PL1584 | 1584.00 | PL6179 | 6179.00 |
PL938 | 938.00 | PL1619 | 1619.00 | PL6259 | 6259.00 |
PL941 | 941.00 | PL1625 | 1625.00 | PL7039 | 7039.00 |
PL945 | 945.00 | PL1630 | 1630.00 | PL7124 | 4641.00 |
PL950 | 950.00 | PL1633 | 1633.00 | ||
PL953 | 953.00 | PL1638 | 1638.00 | ||
PL960 | 960.00 | PL1644 | 1644.00 | ||
PL965 | 965.00 | PL1680 | 1680.00 | ||
PL970 | 970.00 | PL1700 | 1700.00 | ||
PL975 | 975.00 | PL1708 | 1708.00 | ||
PL980 | 980.00 | PL1714 | 1714.00 | ||
PL985 | 985.00 | PL1719 | 1719.00 | ||
PL992 | 992.00 | PL1724 | 1724.00 | ||
PL995 | 995.00 | PL1735 | 1735.00 | ||
PL998 | 998.00 | PL1750 | 1750.00 | ||
PL1000 | 1000.00 | PL1768 | 1768.00 | ||
PL1005 | 1005.00 | PL1774 | 1774.00 | ||
PL1010 | 1010.00 | PL1796 | 1796.00 | ||
PL1015 | 1015.00 | PL1838 | 1838.00 | ||
PL1020 | 1020.00 | PL1845 | 1845.00 | ||
PL1023 | 1023.00 | PL1860 | 1860.00 | ||
PL1030 | 1030.00 | PL1863 | 1863.00 | ||
PL1034 | 1034.00 | PL1876 | 1876.00 | ||
PL1043 | 1043.00 | PL1894 | 1894.00 | ||
PL1049 | 1049.00 | PL1904 | 1904.00 |
